Description&Applications:
Thermal Transfer Ribbon Data Sheet
WO-80500BK (N85)— is an ultra- high durability black resin thermal transfer ribbon, tested and approved for use on KORE AMS-M, HMS-M, DIN-M and HNF-M wire marker sleeves as well as RSFR/AMS/HMS/HNF cable marker tags. For reliable print performance and durability, please use KORE recommended compatible printers.
Characteristics:
Thermal Transfer Ribbon Data Sheet
| Manufacturer |
KORE |
| The max storage temperature |
-5 ℃ -40℃ |
| Operating temperature |
5 ℃ -35℃ |
| The delivery temperature |
-5 ℃ -45℃ |
| Complied standards |
SAE AS 81531 and MIL-STD-202F/215J |
| Ribbon width |
100 mm ； 60mm； 40mm |
| Ribbon length |
300 m |
| Printable area |
100% full area |
| Internal diameter |
25mm |
| Outside diameter |
62mm |
| Ink |
Resin |
| Standard color |
Black |
| Ribbon wind direction |
Ink exterior |
Recommended printers and matgerials:
| Properties |
Typical value |
| Compatible printer |
WO-III,110-600DPI |
| WO-III,110-300DPI |
| Compatible materials |
AMS, HMS, RSFR, HNF |
Packaging and delivery
Packing size:46*46*45cm
Delivery: Any ports of China
Customization
Customized logo Customized packaging Graphic customization
MOQ: 10 MOQ: 10 MOQ: 10
For more customization details, message supplier
FAQ:
Professional Production Quality is Reliable
Q1 . Which certifications or test reports do you have?
A : We have UL,ROHS and REACH.
Q2 . How to ship my order? Is it safe?
A : For small package, we will send it by Express,such as Fedex, UPS,TNT, DHL and so on.
For big packages, we will send them by Air or By sea or by Train. We will use good packing and ensure the safety. We will be responsible to any product damage caused on delivery.”
Q3 . What about your delivery time?
A : We have a lot of products in stock. We can send the stock products in 3 work days.
If without stock,or stock is not enough, we will check the delivery time with you.” (Usually is 3-7days).
Q4 . Can you provide samples? Are the samples free?
A : Yes. We can provide samples.
Usually for our standard products with stock, we can supply samples free for testing.
Q5 . Could I put my own logo on it?
A : Sure, of course, we are a professional manufacture and have over 10 years OEM experience.
