Features:
Flame retardant
Continuous operating temperature:-55°C～+125°C
Minimum shrink temperature:≥+84℃
Fully shrink temperature:≥+120℃
RoHS compliant
Standard Color:Orange(RAL2003)
Technical Parameters:
| Property |
Test Method |
Typical Performance |
| Tensile strength (MPa) |
UL224 |
≥10.4 |
| Elongation (%) |
UL224 |
≥200 |
| Tensile strength after aging (Mpa) |
UL224 158℃X168h |
≥7.3 |
| Elongation after aging (%) |
UL224 158℃X168h |
≥100 |
| Cold Blend |
UL224 -30℃X1h |
No cracking |
| Dielectric Withstand |
UL224 |
4kV,1min without breakdown |
| Dielectric strength (kV/mm) |
UL224 |
≥15 |
| Volume resistivity (Ω·cm) |
UL224 |
≥1X1014 |
| Copper stability |
UL224 158℃X168h |
Pass |
| Anti Corrosion |
UL224 158℃X168h |
Pass |
| Flammbility |
ASTM D2671 C |
VW-1 |
| Ul94 |
V-0(Sample thickness:3mm) |
|
Dimensions:
Packaging and delivery
Packing size:46*46*45cm
Delivery: Any ports of China
Customization
Customized logo Customized packaging Graphic customization
MOQ: 10 MOQ: 10 MOQ: 10
For more customization details, message supplier
