IP67 Black Heat Shrink Cable End Caps Flammability UL 224 VW-1 Heat Shrink Wire End Caps

Large Image : IP67 Black Heat Shrink Cable End Caps Flammability UL 224 VW-1 Heat Shrink Wire End Caps

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	LONG
Certification:	ISO9001
Model Number:	LC-FEP
Document:	End caps price.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	USD 0.8/pcs
Packaging Details:	Carton
Delivery Time:	1-7 days
Payment Terms:	T/T
Supply Ability:	10000pcs / day

Contact Now

IP67 Black Heat Shrink Cable End Caps Flammability UL 224 VW-1 Heat Shrink Wire End Caps

Description

Chemical Resistance:	Excellent	IP Grade:	IP67
Size Range:	10mm - 250mm	Operating Temperature:	-55°C To +125°C
Elongation At Break:	300%	Shrink Ratio:	2.5:1
Insulation:	Excellent	Material:	Polyolefin
Product Name:	Heat Shrink End Caps
Highlight:	IP67 Heat Shrink End Caps , IP67 end cap heat shrink , end cap heat shrink UL 224 VW-1

Elongation At Break 300% Heat Shrink Cable End Caps Rohs Compliant 15 KV/mm Dielectric Strength Heat Shrink Wire End Caps

Product Description:

Heat Shrink End Caps are an essential product for sealing and insulation in various industries, particularly in electrical and telecommunications applications. These end caps are designed to provide a tight seal to prevent the ingress of moisture and contaminants, ensuring the safety and longevity of electrical connections. 3M quality

IP67 Black Heat Shrink Cable End Caps Flammability UL 224 VW-1 Heat Shrink Wire End Caps 0

Features:

Product Name: Heat Shrink End Caps
Water Absorption: 0.2%
Operating Temperature: -55°C To +125°C
Shrink Ratio: 2.5:1
Elongation At Break: 300%
Color: Black
Sealing and Insulation

Technical Parameters:

Product Name	Heat Shrink End Caps
Package Quantity	100 Pieces
Tensile Strength	10.4 MPa
Size Range	10mm - 250mm
Flammability	UL 224 VW-1
Color	Black
Dielectric Strength	15 KV/mm
Chemical Resistance	Excellent
Material	Polyolefin
Operating Temperature	-55°C To +125°C
Rohs Compliant	Yes

Applications:

LONG brand Heat Shrink End Caps

Electrical wiring connections in buildings and infrastructure
Automotive and marine electrical systems
Telecommunications and data networks
Industrial equipment and machinery
Solar power installations

Dimensions

No	Ordinary specification: diameter*high(mm)	Ordinary specification: diameter*high(mm)	Ordinary specification: diameter*high(mm)	Applicable wire outer diameter Φ
1	10×30	10×40	10×50	7—9
2	13×30	13×40	13×80	7—12
3	15×40	15×50	15×100	11—13
4	18×40	18×50	18×100	13—15
5	20×40	20×60	20×100	14—18
6	23×40	23×50	23×60	15—20
7	25×40	25×60	25×65	18—22
8	30×50	30×70	30×100	22—27
9	35×50	35×70	35×100	27—30
10	40×60	40×70	40×120	30—35
11	45×60	45×70	45×120	35—40
12	50×70	50×80	50×120	40—45
13	55×70	55×80	55×120	45—50
14	60×80	60×90		50—55
15	65×80	65×90	65×120	55—60
16	70×90	70×120		60—65
17	75×90	75×120		65—70
18	80×100	80×120		70—75
19	85×100	85×120		75—80
20	90×120	90×150	140×180	80—90
21	95×120	95×150		90—95
22	100×130	100×160	150×180	90—95
23	110×130	110×160	160×180	95—110
24	120×130	120×160		110—120
25		130×160	130×180	120—130
26		140×160	140×180	130—140
27		150×160		140—150
28		160×160		communication cable
29	Inflatable cap
30			(Patent spring-type) exhaust cap	power cable
31			(Patent bypass valve) exhaust cap	high voltage cable

Customization:

Customized logo

Min. order: 100

Customized packaging

Min. order: 100

Graphic customization

Min. order: 100

Customization can be made according to customer requirements

For more customization details, message supplier

Packing and Shipping:

Packaging Details: According to the cap's size
Packing size: 46cm*46cm*45cm

Port: Any ports of China

FAQ

Professional Production Quality is Reliable
Q1 . Which certifications or test reports do you have?
A : We have UL,ROHS and REACH.

Q2 . How to ship my order? Is it safe?
A : For small package, we will send it by Express,such as Fedex, UPS,TNT, DHL and so on.
For big packages, we will send them by Air or By sea or by Train. We will use good packing and ensure the safety. We will be responsible to any product damage caused on delivery.”

Q3 . What about your delivery time?
A : We have a lot of products in stock. We can send the stock products in 3 work days.
If without stock,or stock is not enough, we will check the delivery time with you.” (Usually is 3-7days).

Q4 . Can you provide samples? Are the samples free?
A : Yes. We can provide samples.
Usually for our standard products with stock, we can supply samples free for testing.

Q5 . Could I put my own logo on it?
A : Sure, of course, we are a professional manufacture and have over 10 years OEM experience.
